The Sunward SWE 60UF is a compact excavator featuring a zero-tail swing. Thanks to its design, the SWE 60UF can offer great power at a reduced footprint, giving it the ability to fit into smaller spaces than other similar products. It combines the power of the Kubota V2607-DI-T engine, delivering 36.5 kW, with incredible precision thanks to the dual proportional joysticks and the perfectly fitted hydraulic flow. Its exceptional digging reach performance means no worksite is off-limits. Of course, because we know that safety and comfort should go hand-in-hand, the SWE 60UF keeps you safe and provides every comfort in all working conditions. Last but not least, in the Sunward tradition to always offer the best value for money, the SWE 60UF is no exception since it offers many features and up to 3 years of warranty as standard, at the right price.
Discover all the other advantages of the Sunward SWE 60UF.
SWE 60UF
The Sunward SWE 60UF is a compact excavator featuring a zero-tail swing. Thanks to its design, the SWE 60UF can offer great power at a reduced footprint, giving it the ability to fit into smaller spaces than other similar products. Combining both power and precision, the SWE 60UF offers also a comfortable and safe cab. Last but not least, its exceptional digging reach performance means no worksite is off-limits.
DIMENSIONS
| Operating weight | 5 700 – 5 770 kg | 12,568 lbs. |
| Standard bucket capacity | 0,18 m³ | 47.55 gal |
| Shipping length | 5 500 mm | 18’1″ |
| Shipping width | 1 980 mm | 6’6″ |
| Height over cabin | 2 550 mm | 8’5″ |
ENGINE
| Model | Kubota V2607-DI-T | Kubota V2607-DI-T |
| Emission rating | EU Stage V | EU Stage V |
| Displacement | 2.615 L | 161.7 cu.in. |
| Rated power output | 36.5 kW | 49 HP |
HYDRAULIC SYSTEM
| Type | 2 variable piston pumps + 1 gear pump | 2 variable piston pumps + 1 gear pump |
| Displacement | 2 x 59 L/min + 42 L/min | 24.4 gal/min |
| Hydraulic pressure | 2 x 24.5 Mpa + 21 Mpa |
WORKING RANGE
| Max. digging depth | 3 710 mm | 12’2″/td> |
| Max. digging reach | 6 235 mm | 20′ |
| Max. bucket digging force | 46.8 kN | 10,566 lbf |
| Max. arm digging force | 31.1 kN | 6,969 lbf |
